Technical Requirements

Injection Molding Materials : PBT+30%GF, Black, UL94-V0;

Terminal material :Brass,tinplating 4~6 micrometers,Salt Spray Test 24H.

Terminal insert retention force :1.2*9.5PIN>90N,0.64*0.64>25N

Meet a Criterion : MS201-02, 2011/65/EU ROHS

Dimension tolerance reference : GB/T14486 MT5-A

Geometric tolerance reference : GB/T1184-K
